DRSplus Fundus Camera
iCare

DRSplus Fundus Camera

The DRSplus answers a practical question: how do you get consistent, diagnostic-quality fundus images without depending on one skilled photographer? Its answer is automation: the camera aligns, focuses and captures on its own, so whichever staff member is free can run it. The confocal engine inside is the same TrueColor technology as the EIDON UWF; what you give up is widefield coverage, not image quality, and what you gain is a smaller footprint and a considerably smaller invoice. That trade suits smaller clinics, satellite locations, and comprehensive practices adding imaging deliberately.

Request Pricing → Schedule a Demo → Run the retinal imaging break-even on your numbers →
Practice Fit

Where DRSplus Wins

The DRSplus makes sense when the imaging plan cannot hinge on one experienced photographer being in the building.

Best Fit

Comprehensive optometry and ophthalmology, satellite offices, and any clinic where the imaging has to work no matter who is staffing pretest that day.

Why This

The honest comparison is with the EIDON UWF, its stablemate: same confocal clarity, narrower field, lower cost. If your patient population rarely needs peripheral documentation, paying for widefield is paying for coverage you will not use, and the DRSplus puts that difference back in your equipment budget while your technicians run it unassisted.

Practice Impact

Training a new tech takes a session, not a season; screening and wellness imaging keep moving through staff turnover; and the chart carries consistent images the doctor can show the patient at every follow-up.

Consider Instead

If documented peripheral pathology is central to your patient mix, the EIDON UWF covers 200° where the DRSplus covers a standard field. If you also need visual fields from the same footprint, price the COMPASS against buying two instruments.

Workflow Advantage

Built for Delegation

No practice should have to schedule fundus imaging around one photographer’s shifts. Five automations carry the capture from alignment to finished image, whoever is at the controls.

Tech-Operable

The skill lives in the camera, not the operator: alignment, focus and capture are automated, so a single training session is enough for any staff member to produce diagnostic-quality images.

High Throughput

Both eyes, no dilation, under two minutes, fast enough that imaging never becomes the bottleneck in a full schedule.

Same Confocal Clarity

Same TrueColor confocal engine as the EIDON UWF, same fidelity to clinical color. The two differ in how much retina they show, not how well they show it, so if widefield is not on your requirements list, the DRSplus is the efficient choice.

Image Quality

TrueColor Confocal Imaging Examples

High-resolution retinal images captured with the iCare DRSplus: 10 megapixels at 77 pixels/degree, fully automated and non-mydriatic.

TrueColor fundus image showing age-related macular degeneration

Age-Related Macular Degeneration: TrueColor confocal

TrueColor fundus image showing diabetic retinopathy

Diabetic Retinopathy: TrueColor confocal

TrueColor fundus image showing glaucoma

Glaucoma: TrueColor confocal, nasal view

Red-free imaging modality

Red-Free

Blue imaging modality for RNFL

Blue (RNFL)

Red imaging modality for deep layers

Red (Deep Layers)

Infrared imaging modality for choroid

Infrared (Choroid)

Clinical images courtesy of iCare / Revenio Group. All images captured non-mydriatic.

Specifications

Technical Details
Technology
TrueColor confocal with white LED
Image Resolution
10 megapixels at 77 pixels/degree
Field of View (single)
45° × 40°
Field of View (mosaic)
83° × 78° (up to 9 fields)
Light Sources
White LED (420–675 nm) / Infrared LED (825–870 nm)
Min. Pupil Size
2.5 mm (non-mydriatic)
Autofocus Range
–15D to +15D
Working Distance
25 mm
Display
10.1" integrated touchscreen (1280 × 800)
Storage
SSD ≥480 GB
Export Formats
JPEG, PDF, DICOM, Web API
Dimensions (W × H × D)
300 × 450 × 650 mm (11.8" × 17.7" × 25.6")
Weight
11 kg (24 lbs)
Power
100–240 VAC, 50–60 Hz, 60W / IEC 60601-1 Class I

Specifications reproduced from the manufacturer's published materials and last checked on September 1, 2026. Configurations and specifications change; confirm against the current quote before you rely on them.

The Whitecotton Vision Advantage

What You Get Beyond the Box

Installed in Your Lanes

Delivery is scheduled around your clinic days, the device is configured in your actual exam space, and your staff practices on it hands-on before the visit ends.

Workflow Planning

Where does the device live, who runs it, and how do results reach the doctor? That capture-to-review path gets mapped with your staff before go-live, so the technology fits how your clinic already moves.

Direct Support

When you need help you reach Ryan directly. No call center, no ticket queue, no account manager you have never met.
